NMHC THC CH4 Online Gas Analyzer For Vocs Waste Gas Non-Methane Total Hydrocarbon

Name: NMHC THC CH4 Online Gas Analyzer For Vocs Waste Gas NonMethane Total Hydrocarbon
Brand: JUGE
Price: 1000 USD

Brand Name : JUGE

Model Number : AG-NMHC07

Place of Origin : Nanjing, China

Certification : IOS9001, CE

MOQ : 1 Unit

Price : USD1000-10000

Packaging Details : Neutral carton

Delivery Time : 5-8 working days

Payment Terms : Online order, T/T

Supply Ability : 100 Unit/Week

Parameter : NMHC, THC, CH4

Range : NMHC:(0-200)mgC/m3

Detect limit : 0. 1mg/Nm3

Analyzer Heating : 120ºC

Sample gas : 80kPa- 110kPa

Catalytic Temperature : 200ºC

Contact Now

Online Vocs Waste Gas Non-Methane Total Hydrocarbon Gas Analyzer

>>Overview

The AG-NMHC07 Analyzer is a non-methane hydrocarbon (NMHC) emission monitoring system based on catalytic oxidation and flame ionization detection (FID) principles. It provides real-time measurement of total hydrocarbons (THC) and non-methane hydrocarbons (NMHC) concentrations in industrial flue gases. This analyzer is designed for monitoring organic compound emissions from stationary pollution sources across industries such as petrochemicals, chemical manufacturing, industrial coating, packaging/printing, rubber products, electronics, organic solvent production, automotive manufacturing, pharmaceuticals, and others.

>>Feature

1. Full thermal method with high-temperature analysis throughout the process, effectively preventing sample loss and ensuring accurate and reliable monitoring data;
2. Fast response speed, short analysis cycle, and real-time data output;
3. Simple and quick calibration operation, with calibration time as short as 30 seconds;
4. Compliant with international standards and Chinese national standard HJ1013-2018;
5. 5U standard chassis design for easy integration;
6. Integrated high-temperature pump in the analyzer, supporting direct connection via heated tubing;
7. No carrier gas required;
8. Simultaneous monitoring of NMHC, THC, and CH4;
9. Automatic ignition and hydrogen cutoff after flame extinguishment, ensuring safety and reliability;

>>Technical Parameter

Manufacturer	JUGE	Model	AG-NMHC07
Parameter	NMHC, THC, CH4	Size	500mm×482(435)mm×213mm (L×W×H)
Range	NMHC:(0-200)mgC/m3	Weight	25.2kg
Detect limit	0. 1mg/Nm3	Working environment	(5~40)ºC (0~95)%RH
Analyzer Heating	120ºC	Sample gas	80kPa- 110kPa
Catalytic Temperature	200ºC	Hydrogen Supply	Purity: ≥99.99% Source: Hydrogen cylinder or hydrogen generator Pressure: 0.2 MPa
Repeatability	≤ 1%	Air Supply	Clean air, hydrocarbon concentration ≤0.3 mg/m³ Pressure: 0.4 MPa
Analysis Cycle	≤ 10s(, 300s)	Drive gas	Dehumidified, dust-free, oil-free compressed air Pressure: 0.4 MPa
Zero Point Drift, Span Drift	≤±2%F.S./24h	Calibration Gas	Methane/propane single-component or mixed standard gas Pressure: 0.2 MPa
Linear Error	≤±1%F.S.	Power supply	220 VAC ,50Hz
Catalytic Efficiency	≥98%	Power Consumption	500w , 150W
CH4 Retention Rate	≥98%	Communication Protocol	Modbus
